Infrared Plastic Welder
Product Description
Our infrared plastic welder uses non-contact radiant energy to heat the joining surfaces of thermoplastic components. The infrared emitters transfer energy to the plastic without directly touching the welding ribs. Once the required melt condition is reached, the heating assembly retracts and the fixtures press the components together to complete the joint.
Because there is no direct contact between the heating source and the plastic surface, the infrared plastic welder can reduce sticking, residue transfer, and contamination. It is particularly suitable for visible parts, clean-production applications, and complex welding contours. Multiple heating zones can be independently adjusted to match differences in wall thickness or weld-rib shape. Our infrared plastic welder can also include servo motion, temperature monitoring, data storage, barcode identification, and MES communication.
Specifications
|
Welding process |
Non-contact infrared welding |
|
Heating method |
Infrared radiation |
|
Heating control |
Independently adjustable heating zones |
|
Motion options |
Servo or pneumatic |
|
Control system |
PLC with touchscreen interface |
|
Adjustable parameters |
Heating time, distance, power, pressure, and cooling time |
|
Tooling |
Customized fixtures and infrared heating layout |
|
Safety design |
Protective shielding and interlocked enclosure |
|
Optional functions |
Temperature monitoring, data storage, barcode, and MES interface |
Applications
- Automotive lighting housings and visible plastic parts
- Battery housings and cooling components
- Medical-device and filtration housings
- Appliance tanks and complex plastic shells
- Waterproof electronic enclosures
- Products sensitive to contamination or hot plate sticking
Engineering Support
Our engineers evaluate the plastic material, color, reinforcement content, weld-rib design, part appearance, and sealing requirement before machine design. The infrared-emitter layout is then matched to the actual welding contour.
Quality and Traceability
Infrared output, heating-zone stability, fixture movement, process recipes, and safety protection are tested before shipment. Cycle data, alarms, and selected welding parameters can be recorded when traceability is required.
After-Sales Service
We provide tooling adjustment, process-setting support, operation training, and remote troubleshooting. The equipment is covered by a one-year warranty, and technical support is available throughout installation and production start-up.
Low Maintenance Cost
Without physical contact, there is no need to clean plastic residue from the heating plate. This dramatically reduces equipment downtime and long-term maintenance workload.
Precise Power Calibration
Infrared power and irradiation time can be finely adjusted, allowing for a more precise process window and uniform melting depth control with minimal internal stress.
Easy Operation
The equipment is designed for user-friendliness. This high-end automated model can complete complex infrared welding tasks after simple parameter setting, ensuring high workplace efficiency.
